diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -110,4 +110,4 @@ PersistentKeepalive = 25
 ```

 **You're finished.**
-Make sure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```100.10.202.1```.
+Make sure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```10.200.200.5```.
diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -44,6 +44,12 @@ Here's what we need to add to Host A's ```iptables``` rules, *expressed as the c
 # iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
 ```

+Finally, we need to make sure IP forwarding is enabled in Host A's kernel:
+
+```
+$ sysctl net.ipv4.ip_forward=1
+```
+
 #### Host 'B'

 Host B's ```/etc/wireguard/wg0.conf```:
@@ -79,6 +85,12 @@ PublicKey = <Additional peer pubkey>
 AllowedIPs = 10.200.200.4/32
 ```

+Like we did with Host A, IP forwarding must also be enabled on Host B:
+
+```
+$ sysctl net.ipv4.ip_forward=1
+```
+
 #### Host C

 Host C's configuration file:

diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -66,7 +66,7 @@ PostDown = iptables -D FORWARD -i %i -j ACCEPT; iptables -t nat -D POSTROUTING -

 [Peer]
 PublicKey = <HOST 'A' PUBLIC KEY>
-AllowedIPs = 10.200.200.5/32, 100.101.102.0/24
+AllowedIPs = 10.200.200.5/32, 100.10.202.0/24

 # The smartphone
 [Peer]
@@ -98,4 +98,4 @@ PersistentKeepalive = 25
 ```

 **You're finished.**
-Make sure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```100.101.102.1```.
+Make sure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```100.10.202.1```.
diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -62,7 +62,7 @@ PostDown = iptables -D FORWARD -i %i -j ACCEPT; iptables -t nat -D POSTROUTING -
 #
 # Notice the AllowedIPs... without this part, WireGuard will drop the
 # packets destined for the HOST 'A' subnet.  AllowedIPs is acting like
-# and Access Control List (ACL) here.
+# a routing table and ACL here.

 [Peer]
 PublicKey = <HOST 'A' PUBLIC KEY>
@@ -79,10 +79,6 @@ PublicKey = <Additional peer pubkey>
 AllowedIPs = 10.200.200.4/32
 ```

-The only other thing we need to do on Host B is set up a route so the kernel knows to send traffic destined for Host A's subnet through Host A on the **WireGuard** interface:
-
-```# ip route add 100.101.102.0/24 via 10.200.200.5 dev wg0```
-
 #### Host C

 Host C's configuration file:

diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -79,11 +79,7 @@ PublicKey = <Additional peer pubkey>
 AllowedIPs = 10.200.200.4/32
 ```

-Additional rules for Host B that we need to add, again expressed as the commands used to add them:
-
-```# iptables -t nat -A POSTROUTING -d 100.101.102.0/24 -j MASQUERADE```
-
-The last thing we need to do on Host B is set up a route so the kernel knows to send traffic destined for Host A's subnet through Host A on the **WireGuard** interface:
+The only other thing we need to do on Host B is set up a route so the kernel knows to send traffic destined for Host A's subnet through Host A on the **WireGuard** interface:

 ```# ip route add 100.101.102.0/24 via 10.200.200.5 dev wg0```


diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -106,4 +106,4 @@ PersistentKeepalive = 25
 ```

 **You're finished.**
-Makesure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```100.101.102.1```.
+Make sure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```100.101.102.1```.
diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -39,8 +39,10 @@ PersistentKeepalive = 25                   # to keep connections alive across NA

 Here's what we need to add to Host A's ```iptables``` rules, *expressed as the commands you would use to ADD them*:

-```# iptables -A FORWARD -i wg0-client -j ACCEPT```
-```# iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE```
+```
+# iptables -A FORWARD -i wg0-client -j ACCEPT
+# iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
+```

 #### Host 'B'

@@ -93,12 +95,15 @@ Host C's configuration file:
 [Interface]
 PrivateKey = <HOST 'C' PRIVATE KEY>
 Address = 10.200.200.3/24
-DNS = 1.1.1.1                            # set it to Host B's WireGuard IP if the server is running its own DNS
+DNS = 1.1.1.1


 [Peer]
 PublicKey = <HOST 'B' PUBLIC KEY>
 AllowedIPs = 0.0.0.0/0
 Endpoint = host-b-fqdn.tld:51820
 PersistentKeepalive = 25
-```
+```
+
+**You're finished.**
+Makesure **WireGuard** is running on both HOSTS A and B, and then on the smartphone (HOST C), after connecting to HOST B with **WireGuard** you should be able to ping ```100.101.102.1```.
diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -8,38 +8,97 @@ We want to access a local subnet remotely, but it is behind a NAT firewall and w

 #### Solution Summary

-We'll create a site-to-site connection with **WireGuard** allowing us to access the local subnet by connecting through a cloud server in the middle.
+We'll create a site-to-site connection with **WireGuard** allowing us to access the local subnet on a remote device (smartphone, in this example) by connecting through a cloud server in the middle.

 ## Working Example

 First let's define our three hosts.  They all have **WireGuard** installed.

-```A```  the Linux machine on the *local subnet*, **behind the NAT/firewall**
-```B```  the Linux cloud server (*VPS, like an Amazon EC2 instance*)
-```C```  a third **WireGuard** client; a smartphone in this example
+```A```  the Linux machine on the *local subnet*, **behind the NAT/firewall**
+```B```  the Linux cloud server (*VPS, like an Amazon EC2 instance*)
+```C```  a third **WireGuard** client; a smartphone in this example

 #### Host 'A'

-The local machine's ```/etc/wireguard/wg0-client.conf```:
+The Host A's ```/etc/wireguard/wg0-client.conf```:

 ```conf
 [Interface]
 Address = 10.200.200.5/24
-PrivateKey = <LOCAL MACHINE PRIVATE-KEY>
+PrivateKey = <HOST 'A' PRIVATE-KEY>
 ListenPort = 27836                         # optional; will be randomly assigned otherwise
 DNS = 1.1.1.1                              # or your own DNS server if you're running one

 [Peer]
-PublicKey = <PUBLIC KEY OF MACHINE 'B'>
-Endpoint = machine-b-fqdn.tld:51820
+PublicKey = <PUBLIC KEY OF HOST 'B'>
+Endpoint = host-b-fqdn.tld:51820
 AllowedIPs = 0.0.0.0/0, ::/0

 PersistentKeepalive = 25                   # to keep connections alive across NAT
 ```

-The local machine's ```iptables``` rules, *expressed as the commands you would use to ADD them*:
+Here's what we need to add to Host A's ```iptables``` rules, *expressed as the commands you would use to ADD them*:

-```bash
-# iptables -A FORWARD -i wg0-client -j ACCEPT
-# iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
+```# iptables -A FORWARD -i wg0-client -j ACCEPT```
+```# iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE```
+
+#### Host 'B'
+
+Host B's ```/etc/wireguard/wg0.conf```:
+
+```conf
+[Interface]
+Address = 10.200.200.1/24
+PrivateKey = <HOST 'B' PRIVATE KEY>
+ListenPort = 51820
+
+PostUp = iptables -A FORWARD -i %i -j ACCEPT; iptables -t nat -A POSTROUTING -o ens3 -j MASQUERADE
+PostDown = iptables -D FORWARD -i %i -j ACCEPT; iptables -t nat -D POSTROUTING -o ens3 -j MASQUERADE
+
+
+# This is the peer that is on the private subnet that we want to access.
+#
+# Notice the AllowedIPs... without this part, WireGuard will drop the
+# packets destined for the HOST 'A' subnet.  AllowedIPs is acting like
+# and Access Control List (ACL) here.
+
+[Peer]
+PublicKey = <HOST 'A' PUBLIC KEY>
+AllowedIPs = 10.200.200.5/32, 100.101.102.0/24
+
+# The smartphone
+[Peer]
+PublicKey = <HOST 'C' PUBLIC KEY>
+AllowedIPs = 10.200.200.3/32
+
+# An additional peer...
+[Peer]
+PublicKey = <Additional peer pubkey>
+AllowedIPs = 10.200.200.4/32
+```
+
+Additional rules for Host B that we need to add, again expressed as the commands used to add them:
+
+```# iptables -t nat -A POSTROUTING -d 100.101.102.0/24 -j MASQUERADE```
+
+The last thing we need to do on Host B is set up a route so the kernel knows to send traffic destined for Host A's subnet through Host A on the **WireGuard** interface:
+
+```# ip route add 100.101.102.0/24 via 10.200.200.5 dev wg0```
+
+#### Host C
+
+Host C's configuration file:
+
+```conf
+[Interface]
+PrivateKey = <HOST 'C' PRIVATE KEY>
+Address = 10.200.200.3/24
+DNS = 1.1.1.1                            # set it to Host B's WireGuard IP if the server is running its own DNS
+
+
+[Peer]
+PublicKey = <HOST 'B' PUBLIC KEY>
+AllowedIPs = 0.0.0.0/0
+Endpoint = host-b-fqdn.tld:51820
+PersistentKeepalive = 25
 ```
diff --git a/WireGuard-site-to-site.md b/WireGuard-site-to-site.md
@@ -0,0 +1,45 @@
+# WireGuard Site-to-Site
+
+*Accessing a subnet that is behind a WireGuard client using a site-to-site setup*
+
+#### Problem Summary
+
+We want to access a local subnet remotely, but it is behind a NAT firewall and we can't setup port forwarding.  Outgoing connections work, but all incoming connections get DROPPED by the ISP's routing policy.
+
+#### Solution Summary
+
+We'll create a site-to-site connection with **WireGuard** allowing us to access the local subnet by connecting through a cloud server in the middle.
+
+## Working Example
+
+First let's define our three hosts.  They all have **WireGuard** installed.
+
+```A```  the Linux machine on the *local subnet*, **behind the NAT/firewall**
+```B```  the Linux cloud server (*VPS, like an Amazon EC2 instance*)
+```C```  a third **WireGuard** client; a smartphone in this example
+
+#### Host 'A'
+
+The local machine's ```/etc/wireguard/wg0-client.conf```:
+
+```conf
+[Interface]
+Address = 10.200.200.5/24
+PrivateKey = <LOCAL MACHINE PRIVATE-KEY>
+ListenPort = 27836                         # optional; will be randomly assigned otherwise
+DNS = 1.1.1.1                              # or your own DNS server if you're running one
+
+[Peer]
+PublicKey = <PUBLIC KEY OF MACHINE 'B'>
+Endpoint = machine-b-fqdn.tld:51820
+AllowedIPs = 0.0.0.0/0, ::/0
+
+PersistentKeepalive = 25                   # to keep connections alive across NAT
+```
+
+The local machine's ```iptables``` rules, *expressed as the commands you would use to ADD them*:
+
+```bash
+# iptables -A FORWARD -i wg0-client -j ACCEPT
+# iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
+```
