diff --git a/IncrementalSGD.java b/IncrementalSGD.java
@@ -0,0 +1,283 @@
+/*
+ * Licensed to the Apache Software Foundation (ASF) under one or more
+ * contributor license agreements.  See the NOTICE file distributed with
+ * this work for additional information regarding copyright ownership.
+ * The ASF licenses this file to You under the Apache License, Version 2.0
+ * (the "License"); you may not use this file except in compliance with
+ * the License.  You may obtain a copy of the License at
+ *
+ *    http://www.apache.org/licenses/LICENSE-2.0
+ *
+ * Unless required by applicable law or agreed to in writing, software
+ * distributed under the License is distributed on an "AS IS" BASIS,
+ * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+ * See the License for the specific language governing permissions and
+ * limitations under the License.
+ */
+
+package se.sics.quickstart;
+
+import org.apache.flink.api.common.functions.MapFunction;
+import org.apache.flink.api.common.state.ValueState;
+import org.apache.flink.api.common.state.ValueStateDescriptor;
+import org.apache.flink.api.common.typeinfo.TypeHint;
+import org.apache.flink.api.common.typeinfo.TypeInformation;
+import org.apache.flink.api.java.utils.ParameterTool;
+import org.apache.flink.configuration.Configuration;
+import org.apache.flink.streaming.api.TimeCharacteristic;
+import org.apache.flink.streaming.api.datastream.DataStream;
+import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
+import org.apache.flink.streaming.api.functions.co.CoFlatMapFunction;
+import org.apache.flink.streaming.api.functions.co.CoMapFunction;
+import org.apache.flink.streaming.api.functions.source.SourceFunction;
+import org.apache.flink.streaming.api.functions.windowing.RichAllWindowFunction;
+import org.apache.flink.streaming.api.windowing.windows.GlobalWindow;
+import org.apache.flink.util.Collector;
+
+import java.util.ArrayList;
+import java.util.Collections;
+
+/**
+ * Skeleton for incremental machine learning algorithm consisting of a
+ * pre-computed model, which gets updated for the new inputs and new input data
+ * for which the job provides predictions.
+ *
+ * <p>
+ * This may serve as a base of a number of algorithms, e.g. updating an
+ * incremental Alternating Least Squares model while also providing the
+ * predictions.
+ *
+ * <p>
+ * This example shows how to use:
+ * <ul>
+ *   <li>Connected streams
+ *   <li>CoFunctions
+ *   <li>Tuple data types
+ * </ul>
+ */
+public class IncrementalLearning {
+
+
+	// *************************************************************************
+	// PROGRAM
+	// *************************************************************************
+
+	public static void main(String[] args) throws Exception {
+
+		// Checking input parameters
+		final ParameterTool params = ParameterTool.fromArgs(args);
+
+		Double learningRate = params.has("learningRate") ?  new Double(params.get("learningRate")) : 0.001;
+
+		StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
+		env.setStreamTimeCharacteristic(TimeCharacteristic.ProcessingTime);
+//		env.setParallelism(1);
+
+		// To simplify we make the assumption that the last element in each line is the dependent variable
+		DataStream<ArrayList<Double>> trainingData = env.readTextFile(params.get("training"))
+				.map(new VectorExtractor());
+		DataStream<ArrayList<Double>> newData = env.readTextFile(params.get("test"))
+				.map(new VectorExtractor());
+
+		// build new model on every second of new data
+		DataStream<ArrayList<Double>> model = trainingData
+				.countWindowAll(Integer.parseInt(params.get("batchsize")))
+				.apply(new PartialModelBuilder(learningRate, Integer.parseInt(params.get("dimensions"))));
+
+//		model.print();
+
+		// use partial model for newData
+		DataStream<Double> errors = newData.connect(model).flatMap(new Evaluator());
+
+		errors.print();
+
+		// emit result
+//		if (params.has("output")) {
+//			prediction.writeAsText(params.get("output"));
+//		} else {
+//			System.out.println("Printing result to stdout. Use --output to specify output path.");
+//			prediction.print();
+//		}
+
+		// execute program
+		env.execute("Streaming Incremental Learning");
+	}
+
+	// *************************************************************************
+	// USER FUNCTIONS
+	// *************************************************************************
+
+	/**
+	 * Feeds new data for newData. By default it is implemented as constantly
+	 * emitting the Integer 1 in a loop.
+	 */
+	public static class FiniteNewDataSource implements SourceFunction<Integer> {
+		private static final long serialVersionUID = 1L;
+		private int counter;
+
+		private String filepath;
+
+		public FiniteNewDataSource(int counter, String filepath) {
+			this.counter = counter;
+			this.filepath = filepath;
+		}
+
+		@Override
+		public void run(SourceContext<Integer> ctx) throws Exception {
+			Thread.sleep(15);
+			while (counter < 50) {
+				ctx.collect(getNewData());
+			}
+		}
+
+		@Override
+		public void cancel() {
+			// No cleanup needed
+		}
+
+		private Integer getNewData() throws InterruptedException {
+			Thread.sleep(5);
+			counter++;
+			return 1;
+		}
+	}
+
+	private static Double predict(ArrayList<Double> model, ArrayList<Double> example) {
+		Double prediction = 0.0;
+		for (int i = 0; i < model.size(); i++) {
+			prediction += model.get(i) * example.get(i);
+		}
+		return prediction;
+	}
+
+	/**
+	 * Builds up-to-date partial models on new training data.
+	 */
+	public static class PartialModelBuilder extends RichAllWindowFunction<ArrayList<Double>, ArrayList<Double>, GlobalWindow> {
+
+		public PartialModelBuilder(Double learningRate, int dimensions) {
+			this.learningRate = learningRate;
+			this.dimensions = dimensions;
+		}
+
+		private Double learningRate;
+		private int dimensions;
+		private int applyCount = 0;
+
+		private static final long serialVersionUID = 1L;
+
+		private transient ValueState<ArrayList<Double>> modelState;
+
+		@Override
+		public void open(Configuration config) {
+			ArrayList<Double> allZeroes = new ArrayList<>(Collections.nCopies(dimensions, 0.0));
+			// obtain key-value state for prediction model
+			// TODO: Do random assignment of weights instead of all zeros?
+			ValueStateDescriptor<ArrayList<Double>> descriptor =
+					new ValueStateDescriptor<>(
+							// state name
+							"modelState",
+							// type information of state
+							TypeInformation.of(new TypeHint<ArrayList<Double>>() {}),
+							// default value of state
+							allZeroes);
+			modelState = getRuntimeContext().getState(descriptor);
+		}
+
+		private Double squaredError(Double truth, Double prediction) {
+			return 0.5 * (truth - prediction) * (truth - prediction);
+		}
+
+		private ArrayList<Double> buildPartialModel(Iterable<ArrayList<Double>> trainingBatch) throws Exception{
+			int batchSize = 0;
+			ArrayList<Double> regressionModel = modelState.value();
+			ArrayList<Double> gradientSum = new ArrayList<>(Collections.nCopies(dimensions, 0.0));
+			for (ArrayList<Double> sample : trainingBatch) {
+				batchSize++;
+				Double truth = sample.get(sample.size() - 1);
+				Double prediction = predict(regressionModel, sample);
+				Double error = squaredError(truth, prediction);
+				Double derivative = prediction - truth;
+				for (int i = 0; i < regressionModel.size(); i++) {
+					Double weightGradient = derivative * sample.get(i);
+					Double currentSum = gradientSum.get(i);
+					gradientSum.set(i, currentSum + weightGradient);
+				}
+			}
+			for (int i = 0; i < regressionModel.size(); i++) {
+				Double oldWeight = regressionModel.get(i);
+				Double currentLR = learningRate / Math.sqrt(applyCount);
+				Double change = currentLR * (gradientSum.get(i) / batchSize);
+				regressionModel.set(i, oldWeight - change);
+			}
+			return regressionModel;
+		}
+
+		@Override
+		public void apply(GlobalWindow window, Iterable<ArrayList<Double>> values, Collector<ArrayList<Double>> out) throws Exception {
+			this.applyCount++;
+
+			ArrayList<Double> updatedModel = buildPartialModel(values);
+			modelState.update(updatedModel);
+			out.collect(updatedModel);
+		}
+	}
+
+	public static class Evaluator implements CoFlatMapFunction<ArrayList<Double>, ArrayList<Double>, Double> {
+
+		ArrayList<Double> partialModel = null;
+
+		@Override
+		public void flatMap1(ArrayList<Double> example, Collector<Double> out) throws Exception {
+//            System.out.format("Example: %f\n", example.get(0));
+            if (partialModel != null) {
+                System.out.println("Model was not null!");
+                Double prediction = predict(partialModel, example);
+                Double error = example.get(example.size() - 1) - prediction;
+                out.collect(error);
+            } else {
+                System.out.println("Model was null!");
+            }
+        }
+
+		@Override
+		public void flatMap2(ArrayList<Double> curModel, Collector<Double> out) throws Exception {
+			partialModel = curModel;
+            out.collect(partialModel.get(0));
+		}
+	}
+
+    public static class Predictor implements CoMapFunction<ArrayList<Double>, ArrayList<Double>, Double> {
+        ArrayList<Double> partialModel = null;
+
+        @Override
+        public Double map1(ArrayList<Double> example) throws Exception {
+            if (partialModel != null) {
+                System.out.println("Partial model ready!");
+                return predict(partialModel, example);
+            } else {
+                return Double.NaN;
+            }
+        }
+
+        @Override
+        public Double map2(ArrayList<Double> curModel) throws Exception {
+            partialModel = curModel;
+            return -1.0;
+        }
+    }
+
+
+	public static class VectorExtractor implements MapFunction<String, ArrayList<Double>> {
+		@Override
+		public ArrayList<Double> map(String s) throws Exception {
+			String[] elements = s.split(",");
+			ArrayList<Double> doubleElements = new ArrayList<>(elements.length);
+			for (int i = 0; i < elements.length; i++) {
+				doubleElements.add(new Double(elements[i]));
+			}
+			return doubleElements;
+		}
+	}
+
+}
