    # HAProxy configuration - haproxy-db.cfg

    ##
    ## FRONTEND ##
    ##

    # Load-balanced IPs for DB writes and reads
    #
    frontend db_write
    bind 172.16.0.50:3306
    default_backend cluster_db_write

    frontend db_read
    bind 172.16.0.51:3306
    default_backend cluster_db_read

    # Monitor DB server availability
    #
    frontend monitor_db01
    #
    # set db01_backup to 'up' or 'down'
    #
    bind 127.0.0.1:9301
    mode http
    #option nolinger

    acl no_repl_db01 nbsrv(db01_replication) eq 0
    acl no_repl_db02 nbsrv(db02_replication) eq 0
    acl no_db01 nbsrv(db01_status) eq 0
    acl no_db02 nbsrv(db02_status) eq 0

    monitor-uri /dbs
    monitor fail unless no_repl_db01 no_repl_db02 no_db02
    monitor fail if no_db01 no_db02

    frontend monitor_db02
    #
    # set db02_backup to 'up' or 'down'
    #
    bind 127.0.0.1:9302
    mode http
    #option nolinger

    acl no_repl_db01 nbsrv(db01_replication) eq 0
    acl no_repl_db02 nbsrv(db02_replication) eq 0
    acl no_db01 nbsrv(db01_status) eq 0
    acl no_db02 nbsrv(db02_status) eq 0

    monitor-uri /dbs
    monitor fail unless no_repl_db01 no_repl_db02 no_db01
    monitor fail if no_db01 no_db02

    frontend monitor_db03
    #
    # set db03 read-only slave to 'down'
    #
    bind 127.0.0.1:9303
    mode http
    #option nolinger

    acl no_repl_db03 nbsrv(db03_replication) eq 0
    acl no_repl_db01 nbsrv(db01_replication) eq 0
    acl db02 nbsrv(db02_status) eq 1

    monitor-uri /dbs
    monitor fail if no_repl_db03
    monitor fail if no_repl_db01 db02

    frontend monitor_db04
    #
    # set db04 read-only slave to 'down'
    #
    bind 127.0.0.1:9304
    mode http
    #option nolinger

    acl no_repl_db04 nbsrv(db04_replication) eq 0
    acl no_repl_db01 nbsrv(db01_replication) eq 0
    acl db02 nbsrv(db02_status) eq 1

    monitor-uri /dbs
    monitor fail if no_repl_db04
    monitor fail if no_repl_db01 db02

    frontend monitor_db05
    #
    # set db05 read-only slave to 'down'
    #
    bind 127.0.0.1:9305
    mode http
    #option nolinger

    acl no_repl_db05 nbsrv(db05_replication) eq 0
    acl no_repl_db02 nbsrv(db02_replication) eq 0
    acl db01 nbsrv(db01_status) eq 1

    monitor-uri /dbs
    monitor fail if no_repl_db05
    monitor fail if no_repl_db02 db01

    # Monitor for split-brain syndrome
    #
    frontend monitor_splitbrain
    #
    # set db01_splitbrain and db02_splitbrain to 'up'
    #
    bind 127.0.0.1:9300
    mode http
    #option nolinger

    acl no_repl01 nbsrv(db01_replication) eq 0
    acl no_repl02 nbsrv(db02_replication) eq 0
    acl db01 nbsrv(db01_status) eq 1
    acl db02 nbsrv(db02_status) eq 1

    monitor-uri /dbs
    monitor fail unless no_repl01 no_repl02 db01 db02

    ##
    ## BACKEND ##
    ##

    # Check every DB server replication status
    # - perform an http check on port 9201 (replication status)
    # - set to 'down' if response is '503 Service Unavailable'
    # - set to 'up' if response is '200 OK'
    #
    backend db01_replication
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db01 172.16.0.60:3306 check port 9201 inter 1s rise 1 fall 1

    backend db02_replication
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db02 172.16.0.61:3306 check port 9201 inter 1s rise 1 fall 1

    backend db03_replication
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db03 172.16.0.63:3306 check port 9201 inter 1s rise 1 fall 1

    backend db04_replication
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db04 172.16.0.64:3306 check port 9201 inter 1s rise 1 fall 1

    backend db05_replication
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db05 172.16.0.65:3306 check port 9201 inter 1s rise 1 fall 1

    # Check Master DB server mysql status
    # - perform an http check on port 9200 (mysql status)
    # - set to 'down' if response is '503 Service Unavailable'
    # - set to 'up' if response is '200 OK'
    #
    backend db01_status
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db01 172.16.0.60:3306 check port 9200 inter 1s rise 2 fall 2

    backend db02_status
    mode tcp
    balance roundrobin
    option tcpka
    option httpchk
    server db02 172.16.0.61:3306 check port 9200 inter 1s rise 2 fall 2

    # DB write cluster
    # Failure scenarios:
    # - replication 'up' on db01 & db02 = writes to db01
    # - replication 'down' on db02 = writes to db01
    # - replication 'down' on db01 = writes to db02
    # - replication 'down' on db01 & db02 = go nowhere, split-brain, cluster FAIL!
    # - mysql 'down' on db02 = writes to db01_backup
    # - mysql 'down' on db01 = writes to db02_backup
    # - mysql 'down' on db01 & db02 = go nowhere, cluster FAIL!
    #
    backend cluster_db_write
    #
    # - max 1 db server available at all times
    # - db01 is preferred (top of list)
    # - db_backups set their 'up' or 'down' based on results from monitor_dbs
    #
    mode tcp
    option tcpka
    balance roundrobin
    option httpchk GET /dbs
    server db01 172.16.0.60:3306 weight 1 check port 9201 inter 1s rise 2 fall 1
    server db02 172.16.0.61:3306 weight 1 check port 9201 inter 1s rise 2 fall 1 backup
    server db01_backup 172.16.0.60:3306 weight 1 check port 9301 inter 1s rise 2 fall 2 addr 127.0.0.1 backup
    server db02_backup 172.16.0.61:3306 weight 1 check port 9302 inter 1s rise 2 fall 2 addr 127.0.0.1 backup

    # DB read cluster
    # Failure scenarios
    # - replication 'up' on db01 & db02 = reads on db01, db02, all db_slaves
    # - replication 'down' on db02 = reads on db01, slaves of db01
    # - replication 'down' on db01 = reads on db02, slaves of db02
    # - replication 'down' on db01 & db02 = reads on db01_splitbrain and db01_splitbrain only
    # - mysql 'down' on db02 = reads on db01_backup, slaves of db01
    # - mysql 'down' on db01 = reads on db02_backup, slaves of db02
    # - mysql 'down' on db01 & db02 = go nowhere, cluster FAIL!
    #
    backend cluster_db_read
    #
    # - max 2 master db servers available at all times
    # - max N slave db servers available at all times except during split-brain
    # - dbs track 'up' and 'down' of dbs in the cluster_db_write
    # - db_backups track 'up' and 'down' of db_backups in the cluster_db_write
    # - db_splitbrains set their 'up' or 'down' based on results from monitor_splitbrain
    #
    mode tcp
    option tcpka
    balance roundrobin
    option httpchk GET /dbs
    server db01 172.16.0.60:3306 weight 1 track cluster_db_write/db01
    server db02 172.16.0.61:3306 weight 1 track cluster_db_write/db02
    server db01_backup 172.16.0.60:3306 weight 1 track cluster_db_write/db01_backup
    server db02_backup 172.16.0.61:3306 weight 1 track cluster_db_write/db02_backup
    server db01_splitbrain 172.16.0.60:3306 weight 1 check port 9300 inter 1s rise 1 fall 2 addr 127.0.0.1
    server db02_splitbrain 172.16.0.61:3306 weight 1 check port 9300 inter 1s rise 1 fall 2 addr 127.0.0.1
    #
    # Scaling & redundancy options
    # - db_slaves set their 'up' or 'down' based on results from monitor_dbs
    # - db_slaves should take longer to rise
    #
    server db03_slave 172.16.0.63:3306 weight 1 check port 9303 inter 1s rise 5 fall 1 addr 127.0.0.1
    server db04_slave 172.16.0.64:3306 weight 1 check port 9304 inter 1s rise 5 fall 1 addr 127.0.0.1
    server db05_slave 172.16.0.65:3306 weight 1 check port 9305 inter 1s rise 5 fall 1 addr 127.0.0.1
