  1. Ryan Woodard revised this gist Jul 13, 2017. 2 changed files with 334 additions and 62 deletions.
    261 changes: 199 additions & 62 deletions akmtdfgen.py
    View file
    Original file line number Diff line number Diff line change
    @@ -27,6 +27,36 @@
    Ryan Woodard | AppNexus | Data Science | 2017
    If you have bcolz errors like:
    `start`+`nitems` out of boundsException RuntimeError:
    RuntimeError('fatal error during Blosc
    decompression: -1',) in
    'bcolz.carray_ext.chunk._getitem' ignored
    check that your versions are up to date. Here is what I am using:
    In [1]: import bcolz
    In [2]: bcolz.print_versions()
    -=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=
    bcolz version: 1.1.2
    NumPy version: 1.13.1
    Blosc version: 1.11.2 ($Date:: 2017-01-27 #$)
    Blosc compressors: ['blosclz', 'lz4', 'lz4hc', 'snappy', 'zlib', 'zstd']
    Numexpr version: 2.6.2
    Dask version: not available (version >= 0.9.0 not detected)
    Python version: 2.7.13 |Continuum Analytics, Inc.| (default, Dec 20 2016, 23:09:15)
    [GCC 4.4.7 20120313 (Red Hat 4.4.7-1)]
    Platform: linux2-x86_64
    Byte-ordering: little
    Detected cores: 12
    -=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=
    """
    from __future__ import print_function

    @@ -35,13 +65,65 @@

    import numpy as np
    import pandas as pd
    import bcolz
    import threading

    import os
    import sys
    import glob
    import shutil


    bcolz_lock = threading.Lock()
    # old_blosc_nthreads = bcolz.blosc_set_nthreads(1)
    # assert bcolz.blosc_set_nthreads(1) == 1

    def safe_bcolz_open(fname, idx=None, debug=False):
    """Threadsafe way to read bcolz arrays.
    bcolz might have issues with multithreading and underlying blosc
    compression code. Lots of discussion out there, here are some
    starting points:
    http://www.pytables.org/latest/cookbook/threading.html
    https://github.com/dask/dask/issues/1033
    Since our threads are read-only on the static bcolz array on disk,
    we'll probably be ok, but no guarantees. Test, test, test! It is
    so important that the auxiliary matrix rows stay properly aligned
    with the images DataFrame rows.
    """
    with bcolz_lock:

    if idx is None:
    X2 = bcolz.open(fname)
    else:
    X2 = bcolz.open(fname)[idx]

    if debug:

    df_debug = pd.DataFrame(X2, index=idx)
    # print(len(idx))

    assert X2.shape[0] == len(idx)
    assert X2.shape == df_debug.shape

    # Should see index matching int() of data values.
    # print(df_debug.iloc[:5, :5])
    # print(df_debug.iloc[-5:, -5:])

    df_debug = df_debug.astype(int)
    # print(df_debug.iloc[:5, :5])
    # print(df_debug.iloc[-5:, -5:])

    # Here is why we made the test data as we did. Make sure
    # data cast to int (not rounded up!) matches index values.
    test_idx = (df_debug.subtract(df_debug.index.values, axis=0) == 0).all(axis=1)
    assert test_idx.all(), df_debug[~test_idx]

    return X2


    class threadsafe_iter(object):
    """Takes an iterator/generator and makes it thread-safe by
    serializing call to the `next` method of given iterator/generator.
    @@ -53,6 +135,7 @@ class threadsafe_iter(object):
    def __init__(self, it):
    self.it = it
    self.lock = threading.Lock()
    assert self.lock is not bcolz_lock

    def __iter__(self):
    return self
    @@ -74,11 +157,12 @@ def g(*a, **kw):


    @threadsafe_generator
    def generator_from_df(df, batch_size, target_size, features=None):
    def generator_from_df(df, batch_size, target_size, features=None,
    debug_merged=False):
    """Generator that yields (X, Y).
    If features is not None, assume it is a bcolz array that can be
    indexed by the same indexing of the input df.
    If features is not None, assume it is the path to a bcolz array
    that can be indexed by the same indexing of the input df.
    Assume input DataFrame df has columns 'imgpath' and 'target', where
    'imgpath' is full path to image file.
    @@ -100,9 +184,9 @@ def generator_from_df(df, batch_size, target_size, features=None):
    print().
    """

    if features is not None:
    assert features.shape[0] == df.shape[0], "Features rows must match df!"
    assert os.path.exists(features)
    assert safe_bcolz_open(features).shape[0] == df.shape[0], "Features rows must match df!"

    # Each epoch will only process an integral number of batch_size
    # but with the shuffling of df at the top of each epoch, we will
    @@ -123,6 +207,7 @@ def generator_from_df(df, batch_size, target_size, features=None):
    count = 1
    epoch = 0

    # New epoch.
    while 1:

    # The advantage of the DataFrame holding the image file name
    @@ -135,6 +220,8 @@ def generator_from_df(df, batch_size, target_size, features=None):
    epoch += 1
    i, j = 0, batch_size

    # Mini-batches within epoch.
    mini_batches_completed = 0
    for _ in range(nbatches):

    # Callbacks are more elegant but this print statement is
    @@ -146,6 +233,8 @@ def generator_from_df(df, batch_size, target_size, features=None):

    try:

    # preprocess_input()
    # https://github.com/fchollet/keras/blob/master/keras/applications/inception_v3.py#L389
    X = np.array([

    (2 *
    @@ -162,30 +251,28 @@ def generator_from_df(df, batch_size, target_size, features=None):

    Y = sub.target.values

    if features is not None:
    # For merged model.

    # Important: input df to this function must have
    # index 0 through n - 1. The object_id is a
    # column, not the index. After the shuffle via
    # df.sample() above, do *NOT* reindex the new df
    # because the indexes of the now shuffled df will
    # be used to correctly index into the features
    # dataframe.
    #
    if features is None:

    # Simple model, one input, one output.
    mini_batches_completed += 1
    yield X, Y

    else:

    # For merged model: two input, one output.
    #
    # HEY: You should probably test this very
    # carefully!
    ret = [X, features.loc[sub.index].values], Y

    else:
    # Make (slightly) more efficient by removing the
    # debug_merged check.
    X2 = safe_bcolz_open(features, sub.index.values, debug=debug_merged)

    ret = X, Y

    # preprocess_input()
    # https://github.com/fchollet/keras/blob/master/keras/applications/inception_v3.py#L389
    # yield (X, Y)
    yield ret
    mini_batches_completed += 1

    yield [X, X2], Y
    # Or:
    # yield [X, bcolz.open(features)[sub.index.values]], Y

    except IOError as err:

    @@ -278,8 +365,9 @@ def new_tricks_from_old_dogs(stage, label):
    numbers in the cats/dogs directories are non-unique. This avoids
    collisions.
    """

    old_dogs = glob.glob("data/%s/%ss/*.jpg" % (stage, label))
    s = "data/%s/%ss/*.jpg" % (stage, label)
    #print(s, os.abspath(os.curdir))
    old_dogs = glob.glob(s)
    print(len(old_dogs), stage, label)
    index = list(map(int, [d.split('.')[-2] for d in old_dogs]))
    new_tricks = [file_path_from_db_id(i, pattern='%s_%%d.jpg' % label) for i in index]
    @@ -355,18 +443,41 @@ def get_demo_data():


    def test_generator():
    """Simple function to test return behavior of generator code above."""
    """Simple function to test return behavior of generator code above.
    This runs with and without merged model version.
    df_train:
    object_id imgpath target orig label
    7 1518 /tmp/path/to/imgs/518/01/dog_1518.jpg 1 data/train/dogs/dog.1518.jpg dog
    1113 1662 /tmp/path/to/imgs/662/01/cat_1662.jpg 0 data/train/cats/cat.1662.jpg cat
    980 1409 /tmp/path/to/imgs/409/01/dog_1409.jpg 1 data/train/dogs/dog.1409.jpg dog
    1615 1813 /tmp/path/to/imgs/813/01/cat_1813.jpg 0 data/train/cats/cat.1813.jpg cat
    1029 1760 /tmp/path/to/imgs/760/01/cat_1760.jpg 0 data/train/cats/cat.1760.jpg cat
    df_valid:
    object_id imgpath target orig label
    787 7747 /tmp/path/to/imgs/747/07/cat_7747.jpg 0 data/validation/cats/cat.7747.jpg cat
    165 7563 /tmp/path/to/imgs/563/07/dog_7563.jpg 1 data/validation/dogs/dog.7563.jpg dog
    749 7517 /tmp/path/to/imgs/517/07/cat_7517.jpg 0 data/validation/cats/cat.7517.jpg cat
    458 7742 /tmp/path/to/imgs/742/07/cat_7742.jpg 0 data/validation/cats/cat.7742.jpg cat
    225 7479 /tmp/path/to/imgs/479/07/dog_7479.jpg 1 data/validation/dogs/dog.7479.jpg dog
    """

    pd.np.set_printoptions(linewidth=150)

    df_train, df_valid = get_demo_data()

    img_width, img_height = 150, 150
    batch_size = 16
    batch_size = 64
    target_size = (img_width, img_height)


    print("\nTest basic generator.\n")
    for df in (df_train, df_valid):
    i = 0
    for X, Y in generator_from_df(df, batch_size, target_size, features=None):
    print(X[:3, :3, :1])
    print(X[:3, :3, 0])
    print(Y[:3])
    i += 1
    if i > 1:
    @@ -376,50 +487,76 @@ def test_generator():
    #
    # In the end, this test does not use bcolz.
    # But, if it did, here are some hints to get you there.
    import bcolz

    def save_array_as_bcolz(fname, arr):
    c = bcolz.carray(arr, rootdir=fname, mode='w')
    print("\nTest merged generator.\n")

    nfeatures = 74

    # features_train = pd.np.random.randn(df_train.shape[0], nfeatures)
    # features_valid = pd.np.random.randn(df_valid.shape[0], nfeatures)

    # Make a 2D array, where each row is filled with the values of its
    # index, which will be very convenient for testing the merged
    # model generator.
    # [[0, 0, 0, ...],
    # [1, 1, 1, ...],
    # [2, 2, 2, ...],
    # ...
    # ]
    features_train = np.repeat(np.arange(df_train.shape[0], dtype=float)
    .reshape((-1, 1)),
    nfeatures, axis=1)
    features_valid = np.repeat(np.arange(df_valid.shape[0], dtype=float)
    .reshape((-1, 1)),
    nfeatures, axis=1)

    # Add a litle noise in [0, 1] just to pretend we have "real" data.
    features_train += np.random.rand(*features_train.shape)
    features_valid += np.random.rand(*features_valid.shape)

    fname_train = "mm_features_train_bc"
    if not os.path.exists(fname_train):
    c = bcolz.carray(features_train, rootdir=fname_train, mode='w')
    c.flush()

    nfeatures = 100

    features_train = pd.np.random.randn(df_train.shape[0], nfeatures)
    features_valid = pd.np.random.randn(df_valid.shape[0], nfeatures)

    fname = "features_train.bc"
    if os.path.exists(fname):
    os.remove(fname)
    #save_array_as_bcolz(features_train, fname)

    fname = "features_valid.bc"
    if os.path.exists(fname):
    os.remove(fname)
    #save_array_as_bcolz(features_valid)
    fname_valid = "mm_features_valid_bc"
    if not os.path.exists(fname_valid):
    c = bcolz.carray(features_valid, rootdir=fname_valid, mode='w')
    c.flush()

    # Big assumption here: each row of a features matrix corresponds
    # exactly with the image represented by the row of the associated
    # train or valid df. *YOU* will have to ensure this in your own
    # code. This is only demo code!
    # features_train = pd.DataFrame(bcolz.open("features_train.bc")[:], index=df_train.index)
    # features_valid = pd.DataFrame(bcolz.open("features_valid.bc")[:], index=df_valid.index)
    features_train = pd.DataFrame(features_train, index=df_train.index)
    features_valid = pd.DataFrame(features_valid, index=df_valid.index)

    for df, features in ((df_train, features_train),
    (df_valid, features_valid)):
    for df, fname in ((df_train, fname_train),
    (df_valid, fname_valid)):

    i = 0
    for (X, features), Y in generator_from_df(df, batch_size, target_size,
    features=features):
    nbatches = df.shape[0] / float(batch_size)

    print(X[:3, :3, :1])
    print(features[:3, :5])
    print(Y[:3])
    i += 1
    if i > 1:
    for i, ((X, features), Y) in enumerate(
    generator_from_df(df, batch_size, target_size,
    features=fname, debug_merged=True)):

    if i == 0:
    print(X[:3, :3, 0])
    print(features[:3, :5])
    print(Y[:3])
    else:
    if (i + 1) % 20 == 0:
    print("%d / %d" % (i + i, nbatches), end=', ')
    sys.stdout.flush()

    # Keras automatically breaks out of the infinite "while 1"
    # loop in the generator_from_df(). For this test, we need
    # to break manually.
    if i >= nbatches:
    break

    print("\nSuccessful (I think...) test of multithreaded read of bcolz!")

    print("Note that for this test, all of the above X2 rows should"\
    "have the same int() values within a row.")


    if __name__ == '__main__':
    test_generator()
    135 changes: 135 additions & 0 deletions classifier_from_little_data_script_dfgen_merged.py
    View file
    Original file line number Diff line number Diff line change
    @@ -0,0 +1,135 @@
    '''Script to go with AppNexus blog post.
    Taken from and altered from:
    classifier_from_little_data_script_1.py
    https://gist.github.com/fchollet/0830affa1f7f19fd47b06d4cf89ed44d
    which appears at
    https://blog.keras.io/building-powerful-image-classification-models-using-very-little-data.html
    by Francois Chollet
    It uses data that can be downloaded at:
    https://www.kaggle.com/c/dogs-vs-cats/data
    The rest of this file was written by
    Ryan Woodard | AppNexus | Data Science | 2017
    '''

    #
    # Original code from Francois Chollet, Keras
    #
    import keras
    from keras import backend as K
    from keras.layers import Input, Dense, Conv2D, MaxPooling2D, Flatten, Dropout
    from keras.models import Model

    # dimensions of our images.
    img_width, img_height = 150, 150

    train_data_dir = 'data/train'
    validation_data_dir = 'data/validation'
    nb_train_samples = 2000
    nb_validation_samples = 800
    epochs = 5 #50
    batch_size = 16


    #
    # left branch of model (convnet)
    #
    if K.image_data_format() == 'channels_first':
    input_shape = (3, img_width, img_height)
    else:
    input_shape = (img_width, img_height, 3)

    # This returns a tensor
    linput = Input(shape=input_shape)

    x = Conv2D(32, (3, 3), padding='same', activation='relu')(linput)
    x = MaxPooling2D((2, 2))(x)

    x = Conv2D(32, (3, 3), padding='same', activation='relu')(x)
    x = MaxPooling2D((2, 2))(x)

    x = Conv2D(64, (3, 3), padding='same', activation='relu')(x)
    x = MaxPooling2D((2, 2))(x)

    loutput = Flatten()(x)


    #
    # right branch of model (simple feature data, design matrix)
    #
    nfeatures = 74 # From akmtdfgen.py test_generator()
    rinput = Input(shape=(nfeatures,), name='rinput')


    #
    # Make the merged model.
    #
    x = keras.layers.concatenate([loutput, rinput])
    x = Dense(64, activation='relu')(x)
    x = Dense(64, activation='relu')(x)
    x = Dropout(0.5)(x)

    # And finally we add the main logistic regression layer
    main_output = Dense(1, activation='sigmoid', name='main_output')(x)

    model = Model(inputs=[linput, rinput], outputs=main_output)

    model.compile(loss='binary_crossentropy',
    optimizer='rmsprop',
    metrics=['accuracy'])


    from akmtdfgen import get_demo_data
    from akmtdfgen import generator_from_df

    df_train, df_valid = get_demo_data()

    assert {2} == set([df_train.target.nunique(),
    df_train.label.nunique(),
    df_valid.target.nunique(),
    df_valid.label.nunique()])

    ntrain, nvalid = df_train.shape[0], df_valid.shape[0]

    print("""
    Training set: %d images, 2 classes.
    Validation set: %d images, 2 classes.
    """ % (ntrain, nvalid))


    # lmodel.fit(data, labels) # starts training

    target_size = (img_width, img_height)
    train_generator = generator_from_df(df_train, batch_size, target_size, features="mm_features_train_bc")
    validation_generator = generator_from_df(df_valid, batch_size, target_size, features="mm_features_valid_bc")

    nbatches_train, mod = divmod(ntrain, batch_size)
    nbatches_valid, mod = divmod(nvalid, batch_size)

    nworkers = 10

    # Latest Keras 2.0 API:
    # fit_generator(self, generator, steps_per_epoch, epochs=1, verbose=1,
    # callbacks=None, validation_data=None, validation_steps=None,
    # class_weight=None, max_queue_size=10, workers=1,
    # use_multiprocessing=False, initial_epoch=0)


    model.fit_generator(
    train_generator,
    steps_per_epoch=nbatches_train,
    epochs=epochs,
    verbose=2,
    validation_data=validation_generator,
    validation_steps=nbatches_valid,
    workers=nworkers)


    #lmodel.save_weights('mm_mt_df_gen.h5')
  2. timehaven revised this gist Jul 11, 2017. 1 changed file with 1 addition and 1 deletion.
    2 changes: 1 addition & 1 deletion akmtdfgen.py
    View file
    Original file line number Diff line number Diff line change
    @@ -7,7 +7,7 @@
    Test the generator_from_df() functions by running this file:
    python kmtdfgen.py
    python akmtdfgen.py
    Threadsafe generator code below taken from the answer of user
  3. timehaven revised this gist Jul 11, 2017. 2 changed files with 3 additions and 3 deletions.
    2 changes: 1 addition & 1 deletion kmtdfgen.py → akmtdfgen.py
    View file
    Original file line number Diff line number Diff line change
    @@ -1,4 +1,4 @@
    """kmtdfgen: Keras multithreaded dataframe generator.
    """akmtdfgen: A Keras multithreaded dataframe generator.
    Works with Python 2.7 and Keras 2.x.
    4 changes: 2 additions & 2 deletions classifier_from_little_data_script_dfgen.py
    View file
    Original file line number Diff line number Diff line change
    @@ -72,8 +72,8 @@
    #
    # New code with generator using file path list in DataFrame.
    #
    from kmtdfgen import get_demo_data
    from kmtdfgen import generator_from_df
    from akmtdfgen import get_demo_data
    from akmtdfgen import generator_from_df

    df_train, df_valid = get_demo_data()

  4. timehaven created this gist Jul 11, 2017.
    119 changes: 119 additions & 0 deletions classifier_from_little_data_script_dfgen.py
    View file
    Original file line number Diff line number Diff line change
    @@ -0,0 +1,119 @@
    '''Script to go with AppNexus blog post.
    Taken from and altered from:
    classifier_from_little_data_script_1.py
    https://gist.github.com/fchollet/0830affa1f7f19fd47b06d4cf89ed44d
    which appears at
    https://blog.keras.io/building-powerful-image-classification-models-using-very-little-data.html
    by Francois Chollet
    It uses data that can be downloaded at:
    https://www.kaggle.com/c/dogs-vs-cats/data
    The rest of this file was written by
    Ryan Woodard | AppNexus | Data Science | 2017
    '''

    #
    # Original code from Francois Chollet, Keras
    #
    from keras.preprocessing.image import ImageDataGenerator
    from keras.models import Sequential
    from keras.layers import Conv2D, MaxPooling2D
    from keras.layers import Activation, Dropout, Flatten, Dense
    from keras import backend as K


    # dimensions of our images.
    img_width, img_height = 150, 150

    train_data_dir = 'data/train'
    validation_data_dir = 'data/validation'
    nb_train_samples = 2000
    nb_validation_samples = 800
    epochs = 5 #50
    batch_size = 16

    if K.image_data_format() == 'channels_first':
    input_shape = (3, img_width, img_height)
    else:
    input_shape = (img_width, img_height, 3)

    model = Sequential()
    model.add(Conv2D(32, (3, 3), input_shape=input_shape))
    model.add(Activation('relu'))
    model.add(MaxPooling2D(pool_size=(2, 2)))

    model.add(Conv2D(32, (3, 3)))
    model.add(Activation('relu'))
    model.add(MaxPooling2D(pool_size=(2, 2)))

    model.add(Conv2D(64, (3, 3)))
    model.add(Activation('relu'))
    model.add(MaxPooling2D(pool_size=(2, 2)))

    model.add(Flatten())
    model.add(Dense(64))
    model.add(Activation('relu'))
    model.add(Dropout(0.5))
    model.add(Dense(1))
    model.add(Activation('sigmoid'))

    model.compile(loss='binary_crossentropy',
    optimizer='rmsprop',
    metrics=['accuracy'])


    #
    # New code with generator using file path list in DataFrame.
    #
    from kmtdfgen import get_demo_data
    from kmtdfgen import generator_from_df

    df_train, df_valid = get_demo_data()

    assert {2} == set([df_train.target.nunique(),
    df_train.label.nunique(),
    df_valid.target.nunique(),
    df_valid.label.nunique()])

    ntrain, nvalid = df_train.shape[0], df_valid.shape[0]

    print("""
    Training set: %d images, 2 classes.
    Validation set: %d images, 2 classes.
    """ % (ntrain, nvalid))


    target_size = (img_width, img_height)
    train_generator = generator_from_df(df_train, batch_size, target_size)
    validation_generator = generator_from_df(df_valid, batch_size, target_size)

    nbatches_train, mod = divmod(ntrain, batch_size)
    nbatches_valid, mod = divmod(nvalid, batch_size)

    nworkers = 10

    # Latest Keras 2.0 API:
    # fit_generator(self, generator, steps_per_epoch, epochs=1, verbose=1,
    # callbacks=None, validation_data=None, validation_steps=None,
    # class_weight=None, max_queue_size=10, workers=1,
    # use_multiprocessing=False, initial_epoch=0)


    model.fit_generator(
    train_generator,
    steps_per_epoch=nbatches_train,
    epochs=epochs,
    verbose=2,
    validation_data=validation_generator,
    validation_steps=nbatches_valid,
    workers=nworkers)


    model.save_weights('mt_df_gen.h5')
    426 changes: 426 additions & 0 deletions kmtdfgen.py
    View file
    Original file line number Diff line number Diff line change
    @@ -0,0 +1,426 @@
    """kmtdfgen: Keras multithreaded dataframe generator.
    Works with Python 2.7 and Keras 2.x.
    For Python 3.x, need to fiddle with the threadsafe generator code.
    Test the generator_from_df() functions by running this file:
    python kmtdfgen.py
    Threadsafe generator code below taken from the answer of user
    https://github.com/parag2489
    on the Keras issue
    https://github.com/fchollet/keras/issues/1638
    which uses contributions from
    http://anandology.com/blog/using-iterators-and-generators/
    The rest of this file was written by
    Ryan Woodard | AppNexus | Data Science | 2017
    """
    from __future__ import print_function

    from keras.preprocessing.image import load_img
    from keras.preprocessing.image import img_to_array

    import numpy as np
    import pandas as pd
    import threading

    import os
    import glob
    import shutil


    class threadsafe_iter(object):
    """Takes an iterator/generator and makes it thread-safe by
    serializing call to the `next` method of given iterator/generator.
    https://github.com/fchollet/keras/issues/1638
    http://anandology.com/blog/using-iterators-and-generators/
    """

    def __init__(self, it):
    self.it = it
    self.lock = threading.Lock()

    def __iter__(self):
    return self

    def next(self):
    with self.lock:
    return self.it.next()


    def threadsafe_generator(f):
    """A decorator that takes a generator function and makes it thread-safe.
    https://github.com/fchollet/keras/issues/1638
    http://anandology.com/blog/using-iterators-and-generators/
    """
    def g(*a, **kw):
    return threadsafe_iter(f(*a, **kw))
    return g


    @threadsafe_generator
    def generator_from_df(df, batch_size, target_size, features=None):
    """Generator that yields (X, Y).
    If features is not None, assume it is a bcolz array that can be
    indexed by the same indexing of the input df.
    Assume input DataFrame df has columns 'imgpath' and 'target', where
    'imgpath' is full path to image file.
    https://github.com/fchollet/keras/issues/1627
    https://github.com/fchollet/keras/issues/1638
    Be forewarned if/when you modify this function: some errors will
    not be explicit, appearing only as a generic:
    ValueError: output of generator should be a tuple `(x, y, sample_weight)` or `(x, y)`. Found: None
    It usually means something in your infinite loop is not doing what
    you think it is, so the loop crashes and returns None. Check your
    DataFrame in this function with various print statements to see if
    it is doing what you think it is doing.
    Again, error messages will not be too helpful here--if in doubt,
    print().
    """

    if features is not None:
    assert features.shape[0] == df.shape[0], "Features rows must match df!"

    # Each epoch will only process an integral number of batch_size
    # but with the shuffling of df at the top of each epoch, we will
    # see all training samples eventually, but will skip an amount
    # less than batch_size during each epoch.
    nbatches, n_skipped_per_epoch = divmod(df.shape[0], batch_size)

    # At the start of *each* epoch, this next print statement will
    # appear once for *each* worker specified in the call to
    # model.fit_generator(...,workers=nworkers,...)!
    # print("""
    # Initialize generator:
    # batch_size = %d
    # nbatches = %d
    # df.shape = %s
    # """ % (batch_size, nbatches, str(df.shape)))

    count = 1
    epoch = 0

    while 1:

    # The advantage of the DataFrame holding the image file name
    # and the labels is that the entire df fits into memory and
    # can be easily shuffled at the start of each epoch.
    #
    # Shuffle each epoch using the tricky pandas .sample() way.
    df = df.sample(frac=1) # frac=1 is same as shuffling df.

    epoch += 1
    i, j = 0, batch_size

    for _ in range(nbatches):

    # Callbacks are more elegant but this print statement is
    # included to be explicit.
    # print("Top of generator for loop, epoch / count / i / j = "\
    # "%d / %d / %d / %d" % (epoch, count, i, j))

    sub = df.iloc[i:j]

    try:

    X = np.array([

    (2 *

    # Resizing on the fly is efficient enough for
    # pre-caching when a GPU is training a
    # mini-batch. Here is where some additional
    # data augmentation could take place.
    (img_to_array(load_img(f, target_size=target_size))

    / 255.0 - 0.5))

    for f in sub.imgpath])

    Y = sub.target.values

    if features is not None:
    # For merged model.

    # Important: input df to this function must have
    # index 0 through n - 1. The object_id is a
    # column, not the index. After the shuffle via
    # df.sample() above, do *NOT* reindex the new df
    # because the indexes of the now shuffled df will
    # be used to correctly index into the features
    # dataframe.
    #
    # HEY: You should probably test this very
    # carefully!
    ret = [X, features.loc[sub.index].values], Y

    else:

    ret = X, Y

    # preprocess_input()
    # https://github.com/fchollet/keras/blob/master/keras/applications/inception_v3.py#L389
    # yield (X, Y)
    yield ret


    except IOError as err:

    # A type of lazy person's regularization: with
    # millions of images, if there are a few bad ones, no
    # need to find them, just skip their mini-batch if
    # they throw an error and move on to the next
    # mini-batch. With the shuffling of the df at the top
    # of each epoch, the bad apples will be in a different
    # mini-batch next time around. Yes, they will
    # probably crash that mini-batch, too, but so what?
    # This is easier than finding bad files each time.

    # Let's decrement count in anticipation of the
    # increment coming up--this one won't count, so to
    # speak.
    count -= 1

    # Actually, we could make this a try...except...else
    # with the count increment. Homework assignment left
    # to the reader.

    i = j
    j += batch_size
    count += 1



    def file_path_from_db_id(db_id, pattern="blah_%d.png", top="/tmp/path/to/imgs"):
    """Return file path /top/yyy/xx/blah_zzzxxyyy.png for db_id zzzxxyyy.
    The idea is to hash into 1k top level dirs, 000 - 999, then 100
    second level dirs, 00-99, so that the following database ids
    result in the associated file paths:
    1234567 /tmp/path/to/imgs/567/34/blah_1234567.png
    432 /tmp/path/to/imgs/432/00/blah_432.png
    29847 /tmp/path/to/imgs/847/29/blah_29847.png
    1432 /tmp/path/to/imgs/432/01/blah_1432.png
    Notice that changing pattern to pattern="blah_%09d.png" and
    top="" would result in:
    1234567 567/34/blah_001234567.png
    432 432/00/blah_000000432.png
    29847 847/29/blah_000029847.png
    1432 432/01/blah_000001432.png
    In general, this will give a decent spread for up to 100 million images.
    If you have more than 10 million images, or your database ids are
    higher, then this function is easily modified.
    """
    s = '%09d' % db_id
    return os.path.join(top, s[-3:], s[-5:-3], pattern % db_id)


    #
    # Helper functions, just for blog post demo.
    #
    def new_tricks_from_old_dogs(stage, label):
    """Convert list of Kaggle data files into DataFrame generator format.
    That is, go from:
    cd /path/to/kaggle/data/
    ls train/dogs| head
    to this:
    new orig label
    760 /tmp/path/to/imgs/760/00/dog_760.jpg validation/dogs/dog.760.jpg dog
    7724 /tmp/path/to/imgs/724/07/dog_7724.jpg validation/dogs/dog.7724.jpg dog
    7685 /tmp/path/to/imgs/685/07/dog_7685.jpg validation/dogs/dog.7685.jpg dog
    Only including 'cat' and 'dog' in 'new' file name because the
    numbers in the cats/dogs directories are non-unique. This avoids
    collisions.
    """

    old_dogs = glob.glob("data/%s/%ss/*.jpg" % (stage, label))
    print(len(old_dogs), stage, label)
    index = list(map(int, [d.split('.')[-2] for d in old_dogs]))
    new_tricks = [file_path_from_db_id(i, pattern='%s_%%d.jpg' % label) for i in index]
    return pd.DataFrame({'orig': old_dogs, 'new': new_tricks, 'label': label}, index=index)


    def mv_to_new_hierarchy(row, orig='orig', new='new'):
    """Copy file from orig to new."""
    if os.path.exists(row[new]):
    return
    d, f = os.path.split(row[new])
    os.path.exists(d) or os.makedirs(d) # , exist_ok=True)
    #os.rename(row[orig], row[new]) # If you just want to move, not copy.
    shutil.copy(row[orig], row[new])


    def get_demo_data():
    """Create train and validation DataFrames for blog post demo.
    Create something like this:
    dftrain.sample(5)
    imgpath target orig label
    object_id
    1797 /tmp/path/to/imgs/797/01/cat_1797.jpg 0 train/cats/cat.1797.jpg cat
    1678 /tmp/path/to/imgs/678/01/cat_1678.jpg 0 train/cats/cat.1678.jpg cat
    1348 /tmp/path/to/imgs/348/01/dog_1348.jpg 1 train/dogs/dog.1348.jpg dog
    1430 /tmp/path/to/imgs/430/01/cat_1430.jpg 0 train/cats/cat.1430.jpg cat
    1664 /tmp/path/to/imgs/664/01/cat_1664.jpg 0 train/cats/cat.1664.jpg cat
    dfvalid.sample(5)
    imgpath target orig label
    object_id
    7625 /tmp/path/to/imgs/625/07/cat_7625.jpg 0 validation/cats/cat.7625.jpg cat
    7729 /tmp/path/to/imgs/729/07/cat_7729.jpg 0 validation/cats/cat.7729.jpg cat
    760 /tmp/path/to/imgs/760/00/dog_760.jpg 1 validation/dogs/dog.760.jpg dog
    7724 /tmp/path/to/imgs/724/07/dog_7724.jpg 1 validation/dogs/dog.7724.jpg dog
    7685 /tmp/path/to/imgs/685/07/dog_7685.jpg 1 validation/dogs/dog.7685.jpg dog
    """

    df_train = pd.concat([new_tricks_from_old_dogs('train', 'dog'),
    new_tricks_from_old_dogs('train', 'cat')])

    df_valid = pd.concat([new_tricks_from_old_dogs('validation', 'dog'),
    new_tricks_from_old_dogs('validation', 'cat')])

    # The only time we'll copy image files, just for directory hierarchy demo.
    res = df_train.apply(mv_to_new_hierarchy, axis=1)
    res = df_valid.apply(mv_to_new_hierarchy, axis=1)

    # Belt and suspenders for demo purposes.
    assert all([df['new'].apply(lambda n: os.path.exists(n)).all()
    for df in (df_train, df_valid)])

    # dog will be target 1, cat 0.
    df_train['target'] = (df_train['label'] == 'dog').astype(int)
    df_valid['target'] = (df_valid['label'] == 'dog').astype(int)

    df_train.index.name = 'object_id'
    df_valid.index.name = 'object_id'

    cols = ['imgpath', 'target', 'orig', 'label'] # For ordering.
    df_train = df_train.rename(columns={'new': 'imgpath'})[cols].reset_index()
    df_valid = df_valid.rename(columns={'new': 'imgpath'})[cols].reset_index()

    pd.options.display.width = 200
    print("Some samples:", "", "df_train:", df_train.sample(5), sep='\n')
    print("df_valid:", "", df_valid.sample(5), sep='\n')

    return df_train, df_valid


    def test_generator():
    """Simple function to test return behavior of generator code above."""
    df_train, df_valid = get_demo_data()

    img_width, img_height = 150, 150
    batch_size = 16
    target_size = (img_width, img_height)


    for df in (df_train, df_valid):
    i = 0
    for X, Y in generator_from_df(df, batch_size, target_size, features=None):
    print(X[:3, :3, :1])
    print(Y[:3])
    i += 1
    if i > 1:
    break

    # Create random array for bcolz test.
    #
    # In the end, this test does not use bcolz.
    # But, if it did, here are some hints to get you there.
    import bcolz

    def save_array_as_bcolz(fname, arr):
    c = bcolz.carray(arr, rootdir=fname, mode='w')
    c.flush()

    nfeatures = 100

    features_train = pd.np.random.randn(df_train.shape[0], nfeatures)
    features_valid = pd.np.random.randn(df_valid.shape[0], nfeatures)

    fname = "features_train.bc"
    if os.path.exists(fname):
    os.remove(fname)
    #save_array_as_bcolz(features_train, fname)

    fname = "features_valid.bc"
    if os.path.exists(fname):
    os.remove(fname)
    #save_array_as_bcolz(features_valid)

    # Big assumption here: each row of a features matrix corresponds
    # exactly with the image represented by the row of the associated
    # train or valid df. *YOU* will have to ensure this in your own
    # code. This is only demo code!
    # features_train = pd.DataFrame(bcolz.open("features_train.bc")[:], index=df_train.index)
    # features_valid = pd.DataFrame(bcolz.open("features_valid.bc")[:], index=df_valid.index)
    features_train = pd.DataFrame(features_train, index=df_train.index)
    features_valid = pd.DataFrame(features_valid, index=df_valid.index)

    for df, features in ((df_train, features_train),
    (df_valid, features_valid)):

    i = 0
    for (X, features), Y in generator_from_df(df, batch_size, target_size,
    features=features):

    print(X[:3, :3, :1])
    print(features[:3, :5])
    print(Y[:3])
    i += 1
    if i > 1:
    break


    if __name__ == '__main__':
    test_generator()

    76 changes: 76 additions & 0 deletions make_fake_dirs.py
    View file
    Original file line number Diff line number Diff line change
    @@ -0,0 +1,76 @@
    # Make fake dir structure for lots o' images.
    import os
    import numpy as np
    from numpy.random import choice
    from numpy.random import shuffle
    import pandas as pd


    def util1():
    onek = np.arange(1000)
    onec = np.arange(100)
    nchildren_choices = np.arange(1, 5)
    files = []

    os.chdir('/tmp')

    top = 'imgs'
    if os.path.exists(top):
    os.system('rm -fr %s' % top)
    os.mkdir(top)

    os.chdir(top)

    shuffle(onek)
    nchildren1 = 3
    children1 = ['%03d' % c for c in onek[:nchildren1]]

    for child1 in children1:

    os.mkdir(child1)
    os.chdir(child1)

    shuffle(nchildren_choices)
    shuffle(onec)

    nchildren2 = nchildren_choices[0]
    children2 = ['%02d' % c for c in onec[:nchildren2]]

    for child2 in children2:

    os.mkdir(child2)
    os.chdir(child2)

    shuffle(nchildren_choices)
    shuffle(onek)

    # No leading 0s for files (so '%d', not '%03d').
    nfiles = nchildren_choices[0]
    file_prefixes = ['%d' % c for c in onek[:nfiles]]

    new_files = ['%s%s%s.png' % (f, child2, child1)
    for f in file_prefixes]

    res = [os.system('touch %s' % f) for f in new_files]

    files += new_files

    os.chdir('..')

    os.chdir('..')

    os.chdir('..')
    print("Created %d fake files." % len(files))

    binomial_choices = ['cat', 'dog']
    multinomial_choices = ['black', 'grey', 'white']

    object_ids = sorted([int(f.split('.')[0]) for f in files])
    nobjects = len(files)

    df = (pd.DataFrame({'object_id': object_ids,
    'bi': choice(binomial_choices, nobjects),
    'multi': choice(multinomial_choices, nobjects)})
    [['object_id', 'bi', 'multi']])

    print(df)
